BRONZE NRS GATE VALVE (THREADED)
SPECIFICATION
Presure
Rating:
PN20
Working
Medium:
Water,
Oil,
Steam
Working
Tempurature:
T≤170°C
Taper
Pipe
Thread
To
ISO7
Comply
With
BS5154
Information
PRODUCT DETAIL
| Description | Material |
| Body | Bronze |
| Bonnet | Bronze |
| Stem | DZR Brass |
| Packing Nut | Brass |
| Packing | PTFE |
| Stem Bush | DZR Brass |
| Disc | Bronze |
| Hand Wheel | Alumminum/CI |
| Gasket | PTFE |
Dimension
| mm | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 |
| Inches | 1/2" | 3/4" | 1" | 1.1/4" | 1.1/2" | 2" | 2.1/2" | 3" | 4" |
| L | 43 | 49 | 54 | 62 | 65 | 75 | 87 | 105 | 124 |
| H | 78 | 92 | 103 | 116 | 133 | 155 | 190 | 215 | 256 |
| D | 52 | 60 | 60 | 70 | 78 | 92 | 100 | 110 | 130 |
